Description
A hinge pin is a cylindrical metal rod or pin that serves as the pivot point in a hinge mechanism. It is used to connect two objects, such as a door and its frame, allowing them to rotate or swing relative to each other. The hinge pin consists of a smooth, straight rod of uniform diameter. It is inserted through the hinge knuckles or brackets attached to the objects being hinged. The pin provides a stable and controlled axis of rotation, allowing the object to open and close smoothly.
Attributes
- Designed to withstand forces and stresses.
- Designed with security features to prevent unauthorized removal or tampering.
- Provides support and bears the weight or load of connected objects.
Applications
Hinge pins provide the axis of rotation that allows the cab vent window to open and close smoothly while maintaining a secure connection between the window frame and the window itself. They are mainly used in Cat CCS7, CCS9, CP11, CP12, CP13, CP14, CP16, CP17, CP44B, CP54B, CP56B, CP68B, CP7, CP74B, CP76B, CS10, CS11, CS12, CS13, CS14, CS16, CS17, CS19, CS20, CS44B, CS54B, CS56B, CS64B, CS66B, CS68B, CS7, CS74B, CS76B, CS78B, CS78B, CS79B and CW34 compactors, and RM400, RM600 and RM800 paving equipment.
Specifications
| Pin Type | Ring Groove |
|---|---|
| Diameter | 12.5 mm (0.49 in) |
| Pin Length | 102 mm (4.016 in) |
| Pin Diameter | 10 mm (0.394 in) |
| Overall Length | 103.7 mm (4.08 in) |
| Weight | 0.06 kg (0.14 lb) |
Compatible Equipment
- Compactors: CS7, CS12, CS11, CW-34, CS74B, CS68B, CS54B, CS56B, CP54B, CP56B, CS79B, CS78B, CS-54B, CS64B
- Wheel Loaders: RM400
