348-7062 Press-In Seal
Press-In Seal (Gasket, PIP)
Wholesale only · Full payment before shipment · Send your machine nameplate to confirm fitment
Description
Press-in seals stay fixed in the groove to improve components and prevent leakage and contamination. They are a custom design specific to the application requirements.
Features
Press-in seals are made of materials compatible with the fluids, temperatures, and pressures in Cat® engines and machines. These materials resist abrasion and extrusion and give the seals excellent compression set resistance.
Cat® sealing systems go through a reliable design, testing and validation process. Protect your investment with the latest Genuine Cat® seals.
Applications
Press-in seals are widely used in many static joints on Cat® engines and machines. They are specifically designed for inverted or vertical assemblies.
Specifications
| Overall Length | 720 mm |
|---|---|
| Overall Width | 720 mm |
| Seal/O-Ring Type | PIP |
| Cross-Section Height | 7.3 mm (0.29 in) |
| Cross-Section Width | 4 mm (0.16 in) |
| Inside Diameter | 720 mm (28.4 in) |
| Material | FKM |
| Material Description | FKM rubber has a service temperature range of -40 to 150C and is resistant to air, fuel (including biodiesel), lubricants and engine oil. FKM rubber should not be used in applications requiring water or coolant resistance. |
Compatible Equipment
- Generator Sets: 3512E
- Excavators: 3512C
Additional information
| Machine Model | |
|---|---|
| Equipment Type | |
| Part Source | Genuine OEM |
