348-2377 Electronic Control Assembly
Cat® Electronic Control Assembly (Basic) (A3 High Capacity)
Description
The Cat Engine Controller reads the outputs of various sensors and controls the necessary systems so that Cat heavy equipment achieves optimal engine performance during operation.
Features
- Cast aluminum controller for diesel engines
- High-pressure tolerance tested
- Programmable
- Dust cover
- Labeled, including part and serial numbers
- Designed to work with other Cat parts to ensure the equipment reaches its full potential.
Applications
Cat electronic controls are used to manage engine systems as needed. Refer to your Operation and Maintenance Manual or contact MECHSC for more information. Cat parts are built to work in heavy-duty applications with severe vibration, shock, extreme operating temperature ranges, thermal cycling, thermal shock, humidity, corrosion, and dust.
Specifications
| Material Description | Cast Aluminum |
|---|---|
| Overall Height | 57 mm (2.25 in) |
| Temperature | -40 to 85 (Range) °C (-40 to 185 (Range) °F) |
| Overall Width | 264 mm (10.4 in) |
| Overall Length | 356 mm (14 in) |
Compatible Equipment
- Engines: C15, C7, C18, C12
- Compactors: C-15
- Dozers: D6N, D5N
- Excavators: 3126
- Skid Steer Loaders: 3126B
Additional information
| Machine Model | |
|---|---|
| Equipment Type | |
| Part Source | Genuine OEM |
