Description
Cat joystick base groups are ergonomically designed for operator ease of use. Operators use them to precisely control specific Cat heavy equipment functions.
Features
- Base group and wiring harness
- 6-Pin DT connection
- Straight Mounting Tube
- Cast steel
- RoHS compliant
Applications
Base Groups are used to mount joystick controls on Cat heavy equipment and to provide three-dimensional movement of the input handle. Refer to your Operation and Maintenance Manual or contact MECHSC for more information.
Specifications
| Connector Type | 6-Pin DT |
|---|---|
| Overall Length | 224.7 mm (8.85 in) |
| Overall Width | 92 mm (3.62 in) |
| Overall Height | 92 mm (3.62 in) |
| Pin | 6 |
| Lead Length | 300 mm (11.81 in) |
Compatible Equipment
- Cold Planers: PL61
- Dozers: D1, D4, D3K2 LGP, D6K2, D5K LGP, D5K XL, D5K2 XL
