Description
Choosing Genuine Cat filters, cleaners and precleaners to protect your revenue-generating equipment is always worth it.
Contamination is the number one enemy of engines, so it is critical to protect Cat equipment with Genuine Cat filter elements. Cat Precleaner Groups are ideal for normal-duty applications, providing better engine protection and helping avoid equipment downtime.
Cat air filters offer long service life and superior filtration, and are environmentally friendly and cost-effective. Genuine Cat filters are designed entirely to Cat equipment specifications and are a key factor in how efficiently your machine uses air. A clean filter element protects internal mechanisms from dust damage.
Sticking with Cat air filters ensures long life and optimal performance for your Cat machines.
Features
- Air filter includes primary and secondary elements
- Filter media provides superior protection
- Connecting clamp
- Quick service
- Mounting diameter: 204 mm (8.03 in)
Applications
Refer to your Operation and Maintenance Manual or contact MECHSC for more information.
Specifications
| Overall Width | 436.6 mm (17.189 in) |
|---|---|
| Overall Height | 436.6 mm (17.189 in) |
| Type | Fixed Vane |
| Housing Material | Plastic |
| Scavenge Required | Yes |
| Material | Grease Fluid |
| Outlet Size | 204.4 mm (8.047 in) |
| Overall Diameter | 437 mm (17.20 in) |
| Width | 457 mm (17.992 in) |
| Length | 217.7 mm (8.571 in) |
| Height | 457 mm (17.992 in) |
| Overall Length | 219 mm (8.62 in) |
Compatible Equipment
- Motor Graders: 18, 16, 16M3, 14
- Track Loaders: 990K, 995, 994K, 992, 993
- Cold Planers: PL72, PL83, PL87
- Compactors: C9.3B
- Engines: C13, C15, C18
- Dozers: D8, D10T2, D8T, D9T, D7, D9, D10
- Excavators: 637K, 6015B, 6020B, 6015, 6030
- Wheel Loaders: 966 GC, 992K, 986K
- Skid Steer Loaders: 24
Additional information
| Machine Model | 14, 16, 16M3, 18, 24, 6015, 6015B, 6020B, 6030, 637K, 966 GC, 986K, 990K, 992, 992K, 993, 994K, 995, C13, C15, C18, C9.3B, D10, D10T2, D7, D8, D8T, D9, D9T, PL72, PL83, PL87 |
|---|---|
| Equipment Type | Excavators, Wheel Loaders, Track Loaders, Skid Steer Loaders, Dozers, Motor Graders, Compactors, Cold Planers, Engines |
| Part Source | Genuine OEM |
