330-5045 Wiper Motor Group
Cat® Windshield Wiper Motor Group (12 V)
Fitment data not listed — send us your machine model or serial number to confirm.
Description
Cat windshield wipers clear rain and debris so the operator can see the surroundings clearly in extreme conditions. Because the wiper is a safety device, it should be inspected regularly and replaced as needed so the equipment performs as intended.
Features
- 110 degree sweep
- Includes sealing plug, receptacle group, pin, shroud, cover, lock washer, and nut
- Operating Current at Maximum Load: 3 A
- Maximum Stall Current at High Speed: 8 A
Applications
The Cat wiper motor group consists of a wiper motor with linkage or gears that converts rotary motion to linear motion at the drive nut to drive the wiper arms in the windshield wiper system. Refer to your Operation and Maintenance Manual or contact MECHSC for more information.
Specifications
| Material | Carbon Steel |
|---|---|
| Connector Type | 6-Pin DT |
| Overall Width | 270 mm (10.6 in) |
| Remarks | 35 Cycles/Minute |
| Overall Length | 110 mm (4.3 in) |
| Overall Height | 104 mm (4.1 in) |
Additional information
| Part Source | Genuine OEM |
|---|
