2P-5700 2.03 mm Wire Diameter Compression Spring
Cat® compression spring for transmission selector and pressure control valves, 14 total coils
Description
Cat® springs come in a variety of strengths and sizes to suit specific applications. Our springs are specially designed to deliver excellent performance in many applications, achieving optimal spring rate and assembly load. Cat springs are tested in-house under specific application conditions and have a documented performance history, ensuring consistent component loads and excellent machine reliability and operation for your peace of mind. Cat springs are built to exact specifications to ensure durability, reliability and high productivity over the life of the machine. Cat springs help you build, maintain or repair with confidence. No one else knows your equipment like we do – you can trust Cat.
Features
- Springs meet or exceed current standards and material grades.
- ROHS compliant
- Performance-based
Applications
- Machine and shop applications
Specifications
| Material | Alloy Steel |
|---|---|
| Coating | Phosphate/Oil |
| Material Description | Steel |
| Remarks | Solid Height: 29.3878, Free Length: 53.7718, Assembled Length: 36.0934, Load at Assembled Length: 93.891, Total Coils: 14, Spring Rate NMM: 5.308 |
| Spring Type | Compression |
| Outside Diameter (OD) – A | 5/8 in |
| Length – B | 2 1/8 in |
| Wire Diameter – C | 2.032 in |
Compatible Equipment
- Motor Graders: 140G, 16H
- Off-Highway Trucks: 793, 785, 789
Additional information
| Machine Model | |
|---|---|
| Equipment Type | |
| Part Source | Genuine OEM |
