2G-1034 Air Tank Relief Valve
Cat® Air Tank Relief Valve Releases Excess Pressure, Ensuring Brake System Integrity and Enhancing Operating Safety
Description
Cat relief valves release fluid when a safe threshold is reached to prevent excessive pressure buildup.
Features
- Material: Brass
- Opens at 175 psi (1206.58 kPa)
- Thread Size: 1/4-18 NPTF
- Hex Size: 19.05 mm
Applications
For servicing air tanks and air dryers. Refer to your Operation and Maintenance Manual or contact MECHSC for more information.
Specifications
| Height | 19.05 mm (0.8 in) |
|---|---|
| Length | 63.5 mm (2.5 in) |
| Width | 19.05 mm |
| Hex Size | 19.05 mm (0.75 in) |
| Overall Length | 59.44 mm (2.34 in) |
| Thread Size | 1/4-18 NPTF in |
| Material Description | Brass |
| Pressurization Capability | 1206.58 kPa (175 psi) |
| Material | Alloy Copper |
Compatible Equipment
- Motor Graders: 140 GC, 12K, 140K, 160K, 140G, 120H, 16H, 140H, 120, 12H, 14M, 14
- Excavators: 621G, 637E
- Off-Highway Trucks: 793, 773, 785, 789
