Description
Hose: Cat hoses are used to direct fluids and gases through machine systems. These hoses are made of high-quality materials, can withstand the pressures of specific applications, and meet vibration resistance performance and Cat heavy-duty flow requirements. Cat hydraulic hoses and couplings are tested following the industry's most stringent processes. Each Cat hose and coupling combination is tested as a system to ensure a perfect fit, providing maximum safety and reliability.
The hose is constructed from a special high-temperature synthetic rubber tube; two layers of textile fiber braid combined with a spiral wire running through the fabric reinforcement layer to prevent
Collapses under vacuum. Oil-, weather-, and abrasion-resistant synthetic rubber housing.
Specifications
| Hose Warning | Improper selection of hose and coupling combinations will void the warranty and may result in serious injury or death, property damage, or component and machine system failure. Cat® hose assembly products are designed and tested as a system to achieve reliable connections, maximizing hydraulic system safety and reliability. In addition, use of properly maintained, appropriate Caterpillar tooling is recommended to ensure hoses are crimped to specification. Using Caterpillar hose with another manufacturer's couplings, or Caterpillar couplings with another manufacturer's hose, may result in hose assemblies that are unreliable, unsafe or perform poorly. Caterpillar does not recommend or endorse this practice. For more information, refer to SAE J1273 Section 6.3 and ISO 17165-2 Section 6.3. |
|---|---|
| Material | Low Pressure Hose |
| Hose Inside Diameter | 76.2 mm (3 in) |
| Hose Type | Hydraulic Suction Hose |
| Overall Length | 1220 mm (48.031 in) |
| Weight | 9.023 kg |
Compatible Equipment
- Off-Highway Trucks: 793, 793F
Additional information
| Machine Model | |
|---|---|
| Equipment Type | |
| Part Source | Genuine OEM |
