Description
Cat® fastener parts are designed for specific applications based on size, strength, clamp load and past performance, information other manufacturers do not have. They are carefully selected to last until machine rebuild or end of life. Non-Cat hardware and fasteners may appear to fit your machine, but no one else knows your equipment the way we do.
Hex head bolts/screws provide extremely strong driving capability.
Features
- Cat fasteners are manufactured to precise specifications for durability, reliability and high efficiency
- Strength and Quality – Fasteners meet or exceed ISO, ASTM, ASME and SAE requirements.
- Cat bolts, nuts and washers are specifically designed to work together as a system to maximize clamping force.
Applications
Cat bolts form a high-performance system with mating hardened washers and nuts to produce consistent, high clamping force. You can trust Cat fasteners to help you build, maintain or rebuild in most machine and shop applications worldwide.
Specifications
| Locking Feature | Captive Lockwasher |
|---|---|
| Thread Size | M12 mm (0 in) |
| Thread Direction | RH |
| Thread Size (Diameter × Pitch) | M12 X 1.25 mm |
| Bolt Length | 30 mm (1.181 in) |
| Bolt Type | Hex Head Bolt |
| Handle Length | Not Specified mm (0.315 in) |
| Coating | Not Specified |
Compatible Equipment
- Excavators: 315D L, 320D L, 313D, 323D L, 312D, 314D LCR, 312D L, 314D CR, 320D FM, 311D LRR, 320D GC, 323D, 320D RR, 318D L, 320D
