Description
Cat circuit breakers protect accessory and device wiring against short circuits and overloads. Cat circuit breakers withstand harsh environments.
Features
- Environmentally sealed
- Manual reset button
- Use with size 8 fasteners
Applications
Commonly used to protect the wiring of accessory circuits and devices in construction, marine, mining, and agricultural equipment.
Specifications
| Overall Width | 50.4 mm (1.98 in) |
|---|---|
| Current | 20 Amps |
| Overall Height | 30.2 mm (1.19 in) |
| Overall Length | 50.8 mm (2 in) |
| Material | Phenolic Plastic |
| Type | Manual Reset |
Compatible Equipment
- Generator Sets: 3406C
- Motor Graders: 14, 14M, 16M3, 18, 16
- Wheel Excavators: IT14G, MD6200
- Engines: C32, C27, C15, C7, C18
- Wheel Loaders: 982M, 980M, 966M, 972M
- Off-Highway Trucks: 740, 785D, 797F, 789D, 740B, 772G, 745C, 770G, 793F, 789, 785, 730, 725C2, 725, 735, 793D, 740 GC, 745, 793
Additional information
| Machine Model | 14, 14M, 16, 16M3, 18, 3406C, 725, 725C2, 730, 735, 740, 740 GC, 740B, 745, 745C, 770G, 772G, 785, 785D, 789, 789D, 793, 793D, 793F, 797F, 966M, 972M, 980M, 982M, C15, C18, C27, C32, C7, IT14G, MD6200 |
|---|---|
| Equipment Type | Wheel Excavators, Wheel Loaders, Motor Graders, Off-Highway Trucks, Engines, Generator Sets |
| Part Source | Genuine OEM |
