Description
Cat constant-tension hose clamps are an excellent choice for high-pressure liquid and air applications.
These clamps clamp without leaking and without compromising function. We offer two types of constant-tension clamps: disc clamps and T-bolt clamps. The disc clamp is a lined worm-drive clamp that uses disc washers as constant-tension springs to provide maximum strength and clamping force. The T-bolt clamp uses a T-bolt and spring to provide constant tension and maintains clamping even under the most extreme pressures.
Features
- Material: Stainless steel
- Working Diameter: 27-35 mm (1.06-1.38 in)
- Lined clamp band
- Clamp Type: Wave Liner
Applications
- Disc-style constant-tension clamp suitable for pressures up to 50 PSI
- T-bolt clamp suitable for pressures above 50 PSI
- Refer to your Operation and Maintenance Manual or contact MECHSC for more information.
Specifications
| Working Diameter | 27 – 35 mm (1 1/16 – 1 3/8 in) |
|---|---|
| Hose Clamp Type | Corrugated Liner |
| Maximum Effective Diameter | 35 mm (1.38 in) |
| Clamp Width | 14.2 mm (0.56 in) |
| Material Description | Stainless Steel |
| Minimum Effective Diameter | 27 mm (1.06 in) |
| Material | Stainless Steel |
Compatible Equipment
- Generator Sets: C9
- Track Loaders: 982, 973K, 834H, 824C, 826K, 826H, 972
- Cold Planers: PL87, PL83, PL61, PL72
- Compactors: 825K, 824K, C13B, C9.3B, CW-34, 834K, C-9
- Engines: C7, C13, C15, C11, C27, C18
- Excavators: 390F L, 336D2, 329D, 336D, 330D L, 349F L, 374, 336, 345 GC, 340, 352, 336D L, 395, 350, 355, 637G, 657G, 637E, 637K, 349E L, 349E, 349, 374F L, 349E L VG, 340D2 L, 621G, 621H, 352F, 621K, 340D L, 345D L, M325D L MH, 3508B, 3516B, 336D2 L, 350MHPU, 325D, 329D L, 324D L, 324D, 328D LCR, 330C, 325D L, 330C L, 330D, 326D L, 336D2 XE, 336D2 GC
- Asphalt Pavers: AD30, AD45
- Skid Steer Loaders: 226B3, 3126B, 216B3, 279C, 246C, 262C
- Motor Graders: 18, 14, 16, 349 GC, 16M3, 140G, 140K, 12K, 160K
- Dozers: D8, D7, D9, D10R, D10N, D6T, D6R III, D7E, D6R XL, D6R II, D6T LGP, D6R, D7R, D8N, D8R, D6R LGP, D8T, D9T, D6K2, D10T, D4
- Wheel Loaders: 950H, 980, 980H, 966K, 966H, 972H, 988H, 986H, R3000H, R1700K, R2900G, RM400, 966, 836, 910, R1600H, 988K, 966F, 980G, R2900 XE, 834
- Off-Highway Trucks: 772G, 725C2, 730, 770G, 735, 725
