Description
Cat seals provide a sealing element between mating parts. Keeps equipment leak-free.
Features
- Prevents contaminant ingress
- Oil pan seal
Applications
Used in oil pan groups. Refer to your Operation and Maintenance Manual or contact MECHSC for more information.
Specifications
| Material Hardness | 80A |
|---|---|
| Overall Width | 24.13 mm (0.95 in) |
| Overall Length | 24.13 mm (0.95 in) |
| Overall Height | 3.05 mm (0.12 in) |
| Polymer | NBR (Nitrile butadiene) |
| Cross-Section Diameter | 3 mm (0.118 in) |
| Inside Diameter | 18 mm (0.709 in) |
Compatible Equipment
- Generator Sets: C4.4, C3.3DE50E0, C3.3DE33E0, C7.1, C4.4DE88E0
- Cold Planers: TH360B
- Wheel Excavators: IT14G, M317D2, M313D, M315D, M315D2, M322D
- Compactors: CB-534D, CS-563E, CS-54, CW-34, CS11, CB-564D, CS-56, CB-44B, CB-434D, CS12, CS-533E, CS-54B
- Engines: C6.6
- Dozers: D5K LGP, D5K XL
- Mini Excavators: 307
- Excavators: 312C L, 315C, 312C, 432, 428F, 416E, 416F2, 434F2
- Wheel Loaders: 924HZ, 924GZ, 928HZ, 928G
- Asphalt Pavers: AP-600D
Additional information
| Machine Model | 307, 312C, 312C L, 315C, 416E, 416F2, 428F, 432, 434F2, 924GZ, 924HZ, 928G, 928HZ, AP-600D, C3.3DE33E0, C3.3DE50E0, C4.4, C4.4DE88E0, C6.6, C7.1, CB-434D, CB-44B, CB-534D, CB-564D, CS-533E, CS-54, CS-54B, CS-56, CS-563E, CS11, CS12, CW-34, D5K LGP, D5K XL, IT14G, M313D, M315D, M315D2, M317D2, M322D, TH360B |
|---|---|
| Equipment Type | Excavators, Mini Excavators, Wheel Excavators, Wheel Loaders, Dozers, Compactors, Asphalt Pavers, Cold Planers, Engines, Generator Sets |
| Part Source | Genuine OEM |
