Description
Cat fuses protect the electrical components in Cat machines.
Features
- Cartridge Fuse
- Fuse Type: Time Delay
- Color: Yellow
- Rated Current: 20 Amps
- Rated Voltage: 32 VDC
Applications
Refer to your Operation and Maintenance Manual or contact MECHSC for more information.
Specifications
| Length | 25.4 mm (1 in) |
|---|---|
| Width | 10.92 mm (0.43 in) |
| Height | 11.93 mm (0.47 in) |
Compatible Equipment
- Generator Sets: C4.4
- Compactors: CS7, CB16, CB2.9, CC2.7 GC, CS11, CB-64B, CB-66B, CW-16, CS12, CP12 GC, CS12 GC, CP11 GC, CB2.5 GC, CB2.7 GC, CB2.7, CB2.5, CB13, CB15, CB10
- Dozers: D3K2 LGP, D5K2 XL, D1
- Mini Excavators: 302CR, 301.5, 301.7CR, 308, 310, 305E2, 306, 307E2, 308.5, 306.5, 305.5E2, 305.5 GC
- Excavators: 305E2 CR, 301.8, 301.6, 416E, 428F, 302.7CR, 303.5CR, 303CR, 305 CR, 303.5E2 CR, 307.5, 305
- Asphalt Pavers: AP655F, AP655F L
- Skid Steer Loaders: 216B3, 262C, 279C, 236D, 262D, 226B3, 246D, 246C, 232D, 236B3
Additional information
| Machine Model | 216B3, 226B3, 232D, 236B3, 236D, 246C, 246D, 262C, 262D, 279C, 301.5, 301.6, 301.7CR, 301.8, 302.7CR, 302CR, 303.5CR, 303.5E2 CR, 303CR, 305, 305 CR, 305.5 GC, 305.5E2, 305E2, 305E2 CR, 306, 306.5, 307.5, 307E2, 308, 308.5, 310, 416E, 428F, AP655F, AP655F L, C4.4, CB-64B, CB-66B, CB10, CB13, CB15, CB16, CB2.5, CB2.5 GC, CB2.7, CB2.7 GC, CB2.9, CC2.7 GC, CP11 GC, CP12 GC, CS11, CS12, CS12 GC, CS7, CW-16, D1, D3K2 LGP, D5K2 XL |
|---|---|
| Equipment Type | Excavators, Mini Excavators, Skid Steer Loaders, Dozers, Compactors, Asphalt Pavers, Generator Sets |
| Part Source | Genuine OEM |
