Description
Cat hose assemblies meet the highest standards of quality and reliability. These assemblies are designed to transport liquids or gases and are precisely engineered for each unique application. Every Cat hose assembly uses quality materials and workmanship and is built to meet the pressure and flow requirements of the application, ensuring long machine life and proper operation. Every Cat hose assembly is engineered with the specific application in mind and is designed and manufactured to tight tolerances to ensure a perfect fit with existing systems on Cat machines.
Features
- Hose Inside Diameter: 25.4 mm (1 in)
- Hose Construction: Oil-resistant liner, steel wire reinforcement, heat- and weather-resistant synthetic rubber cover
- Fixed coupling
- End 1 Type: -16 Code 61 Flange
- End 2 Type: 4-Bolt Flange Head with O-Ring Groove
Applications
High-pressure service applications. Refer to your Operation and Maintenance Manual or contact MECHSC for more information.
Specifications
| Material | Other Hose |
|---|---|
| Hose Inside Diameter | 25.4 mm (1 in) |
| Hose Type | 4 or 6 Wire Spiral |
| Overall Length | 630 mm (24.8 in) |
| Weight | 3.157 kg |
Compatible Equipment
- Generator Sets: 3512B
- Excavators: 330D L, 329D L, 320D FM, 336D2 L, 325D L, 320C, 323D L, 336D L, 320D L, 330D, 324D L, 323D2 L, 330C, 330D2 L, 325C, 320D GC, 320D2 L, 325D, 330C L, 323D, 328D LCR, 330D2, 320D2 GC, 326D L, 324D, 336D2 GC, 325C L, 320C L, 323D2, 320D3, 340D2 L, 340D L, M325D L MH, 320D2, 336D, 326D2 L, 336D2, 326D2, 320D, 329D2 L, 329D, 329D2
Additional information
| Machine Model | 320C, 320C L, 320D, 320D FM, 320D GC, 320D L, 320D2, 320D2 GC, 320D2 L, 320D3, 323D, 323D L, 323D2, 323D2 L, 324D, 324D L, 325C, 325C L, 325D, 325D L, 326D L, 326D2, 326D2 L, 328D LCR, 329D, 329D L, 329D2, 329D2 L, 330C, 330C L, 330D, 330D L, 330D2, 330D2 L, 336D, 336D L, 336D2, 336D2 GC, 336D2 L, 340D L, 340D2 L, 3512B, M325D L MH |
|---|---|
| Equipment Type | |
| Part Source | Genuine OEM |
