Description
Choosing Genuine Cat filters to protect your revenue-generating equipment is always worth it.
Cat air filters are available for all Cat equipment models and are recommended for normal-duty filtration. Our filter elements use standard efficiency media to keep dust, soot, sand and other contaminants out of the engine air intake system.
Choosing Cat air filters is a cost-effective way to protect your equipment.
Features
- Air filter includes primary and secondary elements, cover, check valve and bracket
- Air Filter Inlet and Outlet Outside Diameter: 150 mm (5.91 in)
- Straight outlet
- Quick service
Applications
Normal operating conditions. Refer to your Operation and Maintenance Manual or contact MECHSC for more information.
Specifications
| Mounting | Top |
|---|---|
| Outlet Size | 150 mm (5.906 in) |
| Material | Carbon Steel |
| Type | Round |
| Width | 452 mm (17.795 in) |
| Height | 508.3 mm (20.012 in) |
| Length | 679.3 mm (26.744 in) |
| Overall Length | 679 mm (26.74 in) |
| Overall Width | 452 mm (17.80 in) |
| Overall Height | 508 mm (20.01 in) |
Compatible Equipment
- Motor Graders: 16M, 14M
Additional information
| Machine Model | |
|---|---|
| Equipment Type | |
| Part Source | Genuine OEM |
