240-7877 2-Pin Connector Plug
Cat® 20.3 mm Wide 2-Pin Connector Plug for Engine Transmission Wiring Harness
Description
Cat plug group connectors provide a pin and socket connection system for extremely durable, sealed electrical connections in Cat heavy-duty equipment
Features
- Nylon 3-key, 2-pin connector plug
- Black plug body
- Yellow terminal position assurance feature
- Blue perimeter seal
- Light gray wire seal
Applications
Cat connector plug groups use reliable wires between wires or between a wire and equipment. Refer to your Operation and Maintenance Manual or contact MECHSC for more information.
Specifications
| Material | Nylon, 6, 6/12, 6/6 Plastic |
|---|---|
| Overall Length | 34.3 mm (1.4 in) |
| Pin | 2 |
| Wire Gauge | 14-18 AWG |
| Overall Width | 23.5 mm (0.9 in) |
| Overall Depth | 20.3 mm (0.8 in) |
| Material Description | Nylon |
| Connector Type | 2 Pin |
Compatible Equipment
- Generator Sets: C4.4, C9, C7.1
- Track Loaders: 982, 994K, 972, 953, 963, 963K, 826K, 953K, 973K, 995
- Cold Planers: PL61, PM620, PL83, PL87, PM622, PL72
- Compactors: CB-44B, CW-34, CB-64B, CB-66B, CS11, CS12, CB16, 816, 815, 814, 824K, 834K, 825K, CP12 GC, CS12 GC, CP11 GC, C13B, C9.3B, CS7, CB10, C-9, CB15, CB13, CS-54B
- Engines: C15, C13, C7, C18
- Excavators: 330, 390F L, 374F, 374, 313, 349F L, 350, 340, 326, 120 GC, 320 GC, 336, 352, 330GC, 330 GC, 350MHPU, 3508B, 6020B, 320, 432, 6040, 6060, 323, 320E, 336E L, 313F L, 336F, 312F, 336E, 355, 336E H, 315F LCR, 336 GC, 336F L XE, 329E L, 336F L, 335F LCR, 336E LN, 336F LN, 336E LH, 345 GC, 329E, 315, 637K, 349E L VG, 395, 312E L, 312E, 3516E, XQP200, 349E L, 349, 390F, 416F2, 352F, 434F2, 349E, 3516B, 315 GC, 621K, 374F L, 621H, 333, 428F
- Asphalt Pavers: AP655F, AD45
- Motor Graders: 140 GC, 18, 16, 120, 14, 16M3, 316F
- Wheel Excavators: MD6200, M320, M315
- Dozers: D3K2 LGP, D8, D6T LGP, D6N, D9T, D8T, D6T, D6K2, D7E, D5K2 XL, D4, D7, D9
- Wheel Loaders: 950, M314, 834, 950 GC, 980, RM500B, 910, 836, 966, RM400, R1700K, 988K, 926M, 966F, 938M, 966K, R2900 XE
- Off-Highway Trucks: 735, 725, 730, 793, 740, 725C2, 793F, 785, 740B, 740 GC, 796 AC, 794 AC, 770G, 772G, 745C, 797F, 745, 789
