Description
The double-tube loop clip (for example, 239-7957) can secure two hydraulic tubes in place with a single fastener.
Cat clips and clamps are not ordinary off-the-shelf clips and clamps, but another outstanding LET'S DO THE WORK product.
Features
- Steel double tube saddle clamp
- Tube Diameter: 12.7 mm (0.50 in) (2X)
- Clamp Centerline to Fastener Centerline: 46.87 mm (1.85 in)
- Width: 22.4 mm (0.88 in)
- Used with M10 or 3/8 in fasteners
- Cat clips and clamps are built to exact specifications and are durable, reliable and efficient
- Strength and quality – clips and clamps meet or exceed ANSI, ASTM, and DIN requirements
- Cat clips, clamps and fasteners work together as a system to provide outstanding reliability and safety for our customers.
Applications
Refer to your Operation and Maintenance Manual or contact MECHSC for more information.
Specifications
| Length | 46.87 (Clamp Centerline to Fastener Centerline) mm (1.85 (Clamp Centerline to Fastener Centerline) in) |
|---|---|
| Tube Diameter | 12.7 mm (0.50 in) |
| Type | Tube |
| Width | 22.4 mm (0.88 in) |
Compatible Equipment
- Dozers: D11T
- Excavators: 637G, 621G
- Wheel Loaders: 986K, 982M, 980M
- Off-Highway Trucks: 794 AC
Additional information
| Machine Model | |
|---|---|
| Equipment Type | |
| Part Source | Genuine OEM |
