234-4581 Bucket Cylinder Head Support Ring

Description

Backup rings can prevent seal extrusion in high-pressure applications and can also be used to protect the life of the overall sealing system under sudden pressure changes.

Features

Cat® backup rings are designed around the characteristics of the elastomeric seal and mating components and contribute greatly to the life and performance of sealing systems in high-pressure applications.

Backup ring dimensions strictly adhere to tight tolerances, ensuring they properly bridge the seal groove and the mating surfaces. Materials are selected based on their pressure resistance and wear resistance.

Backup rings can be closed rings or split rings. Split rings are used to ensure ease of installation.

Cat sealing systems prevent leaks and contamination of more expensive parts. Protect your investment with Genuine Cat seals.

Applications

Backup rings are used in high-pressure static and dynamic sealing applications, for example, hydraulic pumps, valves, and engine systems.

Specifications

Material	Nylon Plastic
Material Description	Nylon plastic offers good resistance to fuel, oil and lubricants. Many different formulations are available, some of which can support high mechanical loads and provide excellent performance at high temperatures.
Cross-Section Height	2.5 mm (0.1 in)
Cross-Section Width	1.5 mm (0.06 in)
Inside Diameter	130 mm (5.12 in)
Remarks	Dimensions and material descriptions are for reference only. Color may differ from the image.

Compatible Equipment

Generator Sets: 3512B
Excavators: 320, 330 GC, 328D LCR, 320D L, 320D FM, 326D L, 324D L, 326, 330D2, 325, 329D L, 320D2 L, 330D2 L, 320 GC, 325D L, 323D2 L, 329E L, 320D2 GC, 324D, 323D, 329E, 323D L, 330GC, 325D, 335F LCR, 326GC, 326 GC, 333 GC, 395, 320D, 320D2, 330, 326D2, 326D2 L, 329D2 L, 329D, 329D2

Machine Model	320, 320 GC, 320D, 320D FM, 320D L, 320D2, 320D2 GC, 320D2 L, 323D, 323D L, 323D2 L, 324D, 324D L, 325, 325D, 325D L, 326, 326 GC, 326D L, 326D2, 326D2 L, 326GC, 328D LCR, 329D, 329D L, 329D2, 329D2 L, 329E, 329E L, 330, 330 GC, 330D2, 330D2 L, 330GC, 333 GC, 335F LCR, 3512B, 395
Equipment Type	Excavators, Generator Sets
Part Source	Genuine OEM

Machine Model

320, 320 GC, 320D, 320D FM, 320D L, 320D2, 320D2 GC, 320D2 L, 323D, 323D L, 323D2 L, 324D, 324D L, 325, 325D, 325D L, 326, 326 GC, 326D L, 326D2, 326D2 L, 326GC, 328D LCR, 329D, 329D L, 329D2, 329D2 L, 329E, 329E L, 330, 330 GC, 330D2, 330D2 L, 330GC, 333 GC, 335F LCR, 3512B, 395

Equipment Type

Excavators, Generator Sets

Part Source

Genuine OEM
