Description
The Cat® K Series™ system uses a twist-on vertical retainer design that holds securely and is easy to install and remove. K Series tips are designed around the inherent characteristics of your Cat equipment and protect the machine's bucket from damage like no other tip can.
These Heavy Duty tips with Abrasion Resistant Material (ARM) have approximately 60% more wear material in the tip body. ARM is a welding process that bonds very hard tungsten carbide particles into the ground engaging tool, forming a protective layer on the component. This provides superior protection for your equipment and reduces machine downtime.
MECHSC can help you select the right tip for your specific needs and job site conditions, achieving the proper balance between penetration performance and wear life. Now and in the future, choosing Genuine Cat parts is a smart business decision.
Features
- Approximately 60% more wear material in the tip body
- ARM wrapped around the tip for improved penetration
- Up to 5 times longer wear life
Applications
- High wear
- Low to moderate impact
Specifications
| Rear Width | 233 mm (9.173 in) |
|---|---|
| Front Width | 194 mm (7.638 in) |
| Rear Height | 206 mm (8.11 in) |
| Shape | Heavy Duty |
| Overall Length | 485 mm (19.094 in) |
| Wear or Durability | ARM |
| Size | K170 |
| End Bit Size | K170 |
| Series | K Series |
| Material | Alloy Mixed: Metal |
| End Bit Length | 268 mm |
Compatible Equipment
- Excavators: 385B
Additional information
| Machine Model | |
|---|---|
| Equipment Type | |
| Part Source | Genuine OEM |
