Description
Cat® fastener parts are designed for specific applications based on size, strength, clamp load and past performance, information other manufacturers do not have. They are carefully selected to last until machine rebuild or end of life. Non-Cat hardware and fasteners may appear to fit your machine, but no one else knows your equipment the way we do.
These screws can create their own threads. Plastic embossed screws have formed threads that do not crack the plastic boss. There are several types of metal embossed screws, ranging from screws for sheet metal to screws capable of making threads in structural steel.
Features
- Cat fasteners are manufactured to precise specifications for durability, reliability and high efficiency
- Strength and Quality – Fasteners meet or exceed ISO, ASTM, ASME and SAE requirements.
- Cat bolts, nuts and washers are specifically designed to work together as a system to maximize clamping force.
- Coating meets the special requirements of different applications (RoHS compliant).
Applications
Cat bolts form a high-performance system with mating hardened washers and nuts to produce consistent, high clamping force. You can trust Cat fasteners to help you build, maintain or rebuild in most machine and shop applications worldwide.
Specifications
| Material | Alloy Zinc |
|---|---|
| Handle Length | 19 mm |
| Head Height | 5.65 mm |
| Thread Size | M6 mm |
| Material Description | Steel |
| Hole Thread Pitch | 1.00 |
| Head Type | Hex Washer Head |
| Coating | Zinc Electroplated With Topcoat Sealer, 5 Micron Minimum Thickness, 96 Hours Maximum to White Rust |
| Overall Length | 35 mm |
Compatible Equipment
- Generator Sets: 3516C, 3512E, C4.4, C7.1, C9, C4.4DE88E0, 3512B
- Track Loaders: 826K, 963, 963K, 953, 953K, 990K, 834H, 824C, 826H
- Cold Planers: PL61, PL87, PL83, PM622, PM620, PL72
- Compactors: CS11, CS12, 814, 825K, 815, 816, CP56B, CS68B, 834K, CS78B, CS74B, CS56B, 824K, CW-34, CS54B, CP54B, CB-66B, CB-44B, CB16, CB-64B, CW-16, CS79B, CS7, CB13, CB10, CB15, C-9, CS-54B, CS64B
- Engines: C13, C7, C27, C15, C32, C11, C6.6, C175-16, C18
- Excavators: 390D L, 374D L, 336D2, 330, 326D2, 336D, 329D2 L, 329D2, 326D2 L, 329D, 320D, 320D2, 390F L, 330D L, 374, 365C L, 3512C, 6020B, 621G, 637E, 6015 FS, 416F2, 374F L, 345D L, 390D, 340D2 L, 385C FS, 385C, 365C, 6040, 3516E, 330 GC, 336 GC, 336D L, 336D2 L, 328D LCR, 320 GC, 324D L, 336D2 XE, 329D L, 326, 330D, 329E L, 330GC, 330D2 L, 325D L, 312E, 323D2 L, 320, 318D2, 320D2 GC, 330D2, 323 GX, 323, 325, 314D LCR, 320E, 313F L, 326D L, 313D2 GC, 324D, 313D2, 315F LCR, 312F, 336D2 GC, 326GC, 329E, 120 GC, 3101, 323D2, 312E L, 325D, 657G, 320D GC, 323D L, 320 GX, 6015, 6030, 637K, 637G, 333 GC, 326 GC, XQP200, 336, 333, 323 GC, 335F LCR, 323GC, 313D2-GC, 3508B, 6015B, 6018, 434F2, 385C L, 3516B, 428F, 340D L, 314D CR, 318D2 L, 335, 395, 320D L
- Asphalt Pavers: AD30, AP655F, AD45, AP655F L
- Motor Graders: 120, 12K, 14M, 160K, 16M, 140 GC, 140G, 14, 140K, 316F
- Wheel Excavators: M320, M315, MD6250, M317D2, M320D2, M315D2, M315GC, MD6310, MD6200
- Dozers: D6R III, D6T, D6R, D3K2 LGP, D8R, D6N, D6R XL, D8N, D6K2, D6R LGP, D7R, D5K2 XL, D8T, D9T, D7E, D4, D8, D11R, D11T, D11, D10N, D6R II, D10T2, D10R, D10T
- Wheel Loaders: 924K, 938K, 980H, 972L, 966H, 972H, R2900G, R1700G, 950, M314, 950 GC, 950H, 966L, 980G, 950L, 962L, 990H, 988K, RM500B, 966F, 938M, 926M, 988H, R3000H, 986H
- Off-Highway Trucks: 777E, 773E, 730, 773F, 740, 777D, 770G, 725, 740 GC, 772G, 797F, 745C, 745, 793F, 725C2, 775G, 798 AC, 735, 785D, 777, 773
