230-2930 49 mm Wire Reinforced Multi-Bend Coolant Hose
Cat® Upper Radiator Hose (Molded) (Coolant)
Description
Cat molded coolant hoses can be used in the radiator circuit of the engine cooling system and are curve-formed to meet demanding routing requirements.
Features
- Molded upper coolant hose
- Material: Reinforced EPDM
- Hose Inside Diameter: 49 mm (1.93 in)
- Temperature Range: -40° C to 125° C (-40° F to 257° F)
- Burst Pressure: 6.9 bar (100 psi)
- Maximum Working Pressure: 1.7 bar (25 psi)
Applications
Service parts for the radiator cooling system. Refer to your Operation and Maintenance Manual or contact MECHSC for more information.
Specifications
| Material | Coolant Hose Hose |
|---|
Compatible Equipment
- Excavators: 330D L, 336D2 L, 330D, 336D L, 336D2 GC, 340D L, 340D2 L, 336D2, 336D
