Description
Cat high-pressure hydraulic return line.
Features
- 4-layer braid-reinforced hose
- Hose Inside Diameter: 60.5 mm (2.38 in)
- Hose Outside Diameter: 77.1 mm (3.03 in)
- Length: 180 mm (7.08 in)
- Maximum Working Pressure: 2.0 MPa (290 psi)
Applications
High-pressure service applications. Refer to your Operation and Maintenance Manual or contact MECHSC for more information.
Specifications
| Hose Warning | Improper selection of hose and coupling combinations will void the warranty and may result in serious personal injury or death, property damage, or failure of components and machine systems. Cat® hose assembly products are designed and tested as a system to provide reliable connections that maximize hydraulic system safety and reliability. In addition, properly maintained, appropriate Caterpillar tooling is recommended to ensure hoses are crimped to technical specifications. Using Caterpillar hose with another manufacturer's couplings, or Caterpillar couplings with another manufacturer's hose, may result in unreliable, unsafe, or poorly performing hose assemblies. Caterpillar does not recommend or authorize this practice. For more information, refer to SAE J1273 Section 6.3 and ISO 17165-2 Section 6.3. |
|---|---|
| Material | Other Hose |
| Inside Diameter | 77.1 mm (2.38 in) |
| Length | 180 mm (7.08 in) |
| Outside Diameter | 60.5 mm (3.03 in) |
Compatible Equipment
- Wheel Excavators: M315, M315GC
- Excavators: 313, 313 GC, 374, 316 GC, 349F L, 326, 3101, 333, 320 GC, 320 GX, 320, 323 GX, 330 GC, 323, 320D3, 395, 316 GX, 313 GX, 312 GX, 326 GC, 323 GC, 345C, 312 GC, 320D FM, 345D L, 374F L, 323D L, 320D L, 320D2 L, 323D, 320D2 GC, 320C, 323D2 L, 323D2, 320D GC, 326GC, 330GC, 320C L, 323GC, 349E L, 349E, 345C L, 352F, 349D L, 349E L VG, 390F, 345D, 333 GC, 320D2, 320D, 330, 349D2, 390F L, 374F, 349D2 L, 349D
Additional information
| Machine Model | 3101, 312 GC, 312 GX, 313, 313 GC, 313 GX, 316 GC, 316 GX, 320, 320 GC, 320 GX, 320C, 320C L, 320D, 320D FM, 320D GC, 320D L, 320D2, 320D2 GC, 320D2 L, 320D3, 323, 323 GC, 323 GX, 323D, 323D L, 323D2, 323D2 L, 323GC, 326, 326 GC, 326GC, 330, 330 GC, 330GC, 333, 333 GC, 345C, 345C L, 345D, 345D L, 349D, 349D L, 349D2, 349D2 L, 349E, 349E L, 349E L VG, 349F L, 352F, 374, 374F, 374F L, 390F, 390F L, 395, M315, M315GC |
|---|---|
| Equipment Type | |
| Part Source | Genuine OEM |
