Description
XT ES (Enhanced Spiral) high-pressure hose carries petroleum-based hydraulic oil at high pressure from pumps and motors to machine components.
Features
Made with a fabric-reinforced synthetic rubber tube and four to six layers of spiral-wrapped high-tensile steel wire reinforcement (separated by layers of synthetic rubber). The synthetic rubber cover is oil-, weather- and abrasion-resistant. XT ES hoses have been impulse tested to 1,000,000 cycles (twice the number of cycles required by SAE). In addition, Cat® XT ES hoses have a working bend radius of only half the SAE bend radius. This means they bend more easily in tight spaces and significantly reduce hose length requirements. These features simplify installation, extend service life and deliver outstanding reliability.
Recommended Applications:
High-pressure service applications.
Specifications
| Hose Warning | Improper selections of hose and coupling combinations will void warranties and may result in serious personal injury or death, property damage, or component and machine system failure. Cat® hose assembly products are designed and tested as a system to achieve a reliable connection, thus maximizing hydraulic system safety and dependability. It is also recommended that appropriate and properly maintained Caterpillar tooling is used to ensure hoses are crimped to specifications. Use of Caterpillar hose with other manufacturer's couplings or the use of Caterpillar couplings with other manufacturer's hose may result in the production of unreliable, unsafe or under-performing hose assemblies. It is not recommended or authorized by Caterpillar. For additional information see SAE J1273 section 6.3 and ISO 17165-2 section 6.3. |
|---|---|
| Material | High Pressure Hose |
| Hose Type | 4 or 6 Wire Spiral – XT-6ES Hose |
| Hose Inside Diameter | 32 mm (1.26 in) |
| Overall Length | 1400 mm (55.118 in) |
| Weight | 7.301 kg |
Compatible Equipment
- Excavators: 330C L, 330C
Additional information
| Machine Model | |
|---|---|
| Equipment Type | |
| Part Source | Genuine OEM |
