Description
Cat® K Series adapters offer unmatched manufacturing precision to protect your machine's bucket from damage. Our bucket ground engaging tools (G.E.T) are designed around the inherent characteristics of your Cat equipment to provide consistently superior protection.
Cat® corner shroud adapters provide superior corner protection along with all the added penetration benefits of the bucket tooth.
Our adapters are durable and cast from steel that holds its hardness and offers long wear life, so your machine delivers the performance you need. Always choose Genuine Cat bucket protection to protect your investment.
Features
- K100 left bolt-on corner shroud adapter fits a 45 mm base edge with a 22.5 degree bevel angle
Applications
- Wheel Loader Buckets
Specifications
| Attachment Method | Bolt-On |
|---|---|
| Width | 122.1 mm (4.807 in) |
| Bottom Bar Length | 0 mm (0 in) |
| Hole Spacing | 153 mm |
| Overall Length | 463 mm (18.228 in) |
| Hole Size | 1-1/4-in Plow Bolt (36.5 mm square) |
| Bevel Angle | 22.5 |
| Base Edge Thickness Grade | 45 |
| Number of Holes | 2 |
| Corner Stop Angle | 2 |
| Size | K100 |
| Type | Bolt-On Two Strap |
| Series | K Series |
| Position | LH Corner |
| Wear or Durability | Standard |
Compatible Equipment
- Track Loaders: 982
- Wheel Loaders: 982M, 980M
Additional information
| Machine Model | |
|---|---|
| Equipment Type | |
| Part Source | Genuine OEM |
