Description
Press-in seals stay fixed in the groove to improve assembly performance and prevent leakage and contamination. They are a custom design specific to the application requirements.
Features
Press-in seals are made of materials compatible with the fluids, temperatures, and pressures in Cat® engines and machines. These materials resist abrasion and extrusion and give the seals excellent compression set resistance.
Cat® sealing systems go through a robust design, testing and validation process. Protect your investment with the latest Genuine Cat® seals.
Applications
Press-in seals are widely used in many static joints on Cat® engines and machines. They are specifically designed for inverted or vertical assemblies.
Specifications
| Overall Width | 912 mm |
|---|---|
| Overall Length | 912 mm |
| Seal/O-Ring Type | PIP |
| Cross-Section Height | 7.3 mm (0.29 in) |
| Cross-Section Width | 4 mm (0.16 in) |
| Material | FKM |
| Material Description | FKM rubber has a service temperature range of -40 to 150C and is resistant to air, fuel (including biodiesel), lubricants and engine oil. FKM rubber should not be used in applications requiring water or coolant resistance. |
Compatible Equipment
- Track Loaders: 993, 990K, 992
- Wheel Excavators: MD6250, MD6310
- Engines: C32, C27
- Dozers: D11T, D11R, D10T, D10N, D6T, D11, D10T2, D10R, D10
- Excavators: 6015B, 6020B, 6030, 6040, 6015
- Wheel Loaders: 992K
- Off-Highway Trucks: 777, 777E, 777D, 775G, 773F, 773
- Asphalt Pavers: AD63
- Skid Steer Loaders: 24
Additional information
| Machine Model | 24, 6015, 6015B, 6020B, 6030, 6040, 773, 773F, 775G, 777, 777D, 777E, 990K, 992, 992K, 993, AD63, C27, C32, D10, D10N, D10R, D10T, D10T2, D11, D11R, D11T, D6T, MD6250, MD6310 |
|---|---|
| Equipment Type | Excavators, Wheel Excavators, Wheel Loaders, Track Loaders, Skid Steer Loaders, Dozers, Off-Highway Trucks, Asphalt Pavers, Engines |
| Part Source | Genuine OEM |
