Description
Choosing Genuine Cat® filters to protect your revenue-generating equipment is always worth it.
Cat standard efficiency cab air filters fit all Cat equipment models and are recommended for normal-duty filtration. Our filter elements use standard efficiency media to keep dust, soot, sand, and other contaminants out of the cab, providing a healthier, more comfortable work environment.
Protecting your equipment and operators is essential, so choosing Cat cab filter elements is a cost-effective way to achieve both goals.
Features
- Fits current filter housing without modification
Applications
- Normal operating conditions
Note: The cab air filter should not be used to filter hazardous materials.
Specifications
| Material | Carbon Steel |
|---|---|
| Height | 35.5 mm (1.4 in) |
| Width | 164 mm (6.457 in) |
| Weight | 1.07 kg (2.36 lb) |
| Length | 400 mm (15.748 in) |
| Type | Urethane Panel |
| Overall Length | 400 mm (15.748 in) |
| Overall Width | 164 mm (6.457 in) |
| Height With Seal | 35.5 mm (1.398 in) |
| Media Type | Standard |
| Efficiency Rating | Standard Efficiency |
| Height Without Seal | 25.5 mm (1.004 in) |
Compatible Equipment
- Motor Graders: 14M, 16M, 18, 16, 14, 16M3
- Excavators: 416F2, 432, 434F2, 428F, 416E
- Off-Highway Trucks: 773, 777, 775G
