Description
Cat® fastener parts are designed for specific applications based on size, strength, clamp load and past performance, information other manufacturers do not have. They are carefully selected to last until machine rebuild or end of life. Non-Cat hardware and fasteners may appear to fit your machine, but no one else knows your equipment the way we do.
These bolts are used where a separate washer is not needed.
Features
- Cat fasteners are manufactured to precise specifications for durability, reliability and high efficiency
- Strength and Quality – Fasteners meet or exceed ISO, ASTM, ASME and SAE requirements.
- Cat bolts, nuts and washers are specifically designed to work together as a system to maximize clamping force.
- Coating meets the special requirements of different applications (RoHS compliant).
Applications
Cat bolts form a high-performance system with mating hardened washers and nuts to produce consistent, high clamping force. You can trust Cat fasteners to help you build, maintain or rebuild in most machine and shop applications worldwide.
Specifications
| Thread Size (Diameter × Pitch) | M8x1.25 mm |
|---|---|
| Coating | Zinc Phosphate + Oil |
| Class or Grade | ISO 898-1 Class 10.9 |
| Locking Feature | None |
| Thread Direction | RH |
| Thread Size | M8 mm (0 in) |
| Flange Diameter | 17 mm |
| Remarks | Thread Length (mm) 3 |
| Bolt Length | 20 mm (0.787 in) |
| Bolt Type | Hex Flange Head |
| Handle Length | 3 mm (0.118 in) |
Compatible Equipment
- Generator Sets: C9, C4.4, C7.1, DG30, 3512B, 3516C
- Track Loaders: 982
- Motor Graders: 14, 16M, 18, 16, 16M3, 14M
- Compactors: CS-56, C13B
- Engines: C13, C6.6, C32, C11, C15, C27, C175-16, C18
- Dozers: D8, D6T, D8N, D8T, D7
- Excavators: 349F L, 352, 355, 349, 3516B, 3508B, 432, 345C, 345D L, 352F, 621K, 349E L VG, 621H, 428F, 349D L, 345C L, 416E, 349E L, 349E, 3516E, 345D, 416F2, 3512C, 434F2, 349D, 349D2, 349D2 L
- Wheel Loaders: R1700G, R1600H, R1700K, 980L, 980, 972H, 966H
- Off-Highway Trucks: 794 AC, 725, 730, 797F, 735, 793F
Additional information
| Machine Model | 14, 14M, 16, 16M, 16M3, 18, 345C, 345C L, 345D, 345D L, 349, 349D, 349D L, 349D2, 349D2 L, 349E, 349E L, 349E L VG, 349F L, 3508B, 3512B, 3512C, 3516B, 3516C, 3516E, 352, 352F, 355, 416E, 416F2, 428F, 432, 434F2, 621H, 621K, 725, 730, 735, 793F, 794 AC, 797F, 966H, 972H, 980, 980L, 982, C11, C13, C13B, C15, C175-16, C18, C27, C32, C4.4, C6.6, C7.1, C9, CS-56, D6T, D7, D8, D8N, D8T, DG30, R1600H, R1700G, R1700K |
|---|---|
| Equipment Type | Excavators, Wheel Loaders, Track Loaders, Dozers, Motor Graders, Off-Highway Trucks, Compactors, Engines, Generator Sets |
| Part Source | Genuine OEM |
