Description
Choosing Genuine Cat® filters to protect your revenue-generating equipment is always worth it.
Contamination is the number one enemy of engines, so it is critical to protect Cat equipment with Genuine Cat filter elements. Cat Standard Efficiency Primary Engine Air Filters are ideal for normal-duty applications, providing better engine protection and helping avoid equipment downtime.
Cat air filters offer long service life, superior filtration performance, and are environmentally friendly and cost-effective. Genuine Cat filters are designed entirely to Cat equipment specifications and are a key factor in how efficiently your machine uses air. A clean filter element protects internal mechanisms from dust damage.
Sticking with Cat air filters ensures long life and optimal performance for your Cat machines.
Features
- Quick to service
- Improved contamination control retains particles during filter changes
Specifications
| Material | Carbon Steel |
|---|---|
| Type | Two Strap |
| Primary and Secondary | Primary |
| Seal Type | Radial Seal |
| Overall Depth | 387.5 mm (15.256 in) |
| Overall Width | 186.4 mm (7.339 in) |
| Overall Height | 186.4 mm (7.339 in) |
| Height | 186.4 mm (7.339 in) |
| Depth | 387.5 mm (15.256 in) |
| Width | 186.4 mm (7.339 in) |
| Media Type | Standard |
| Shape | Round |
| Efficiency Rating | Standard Efficiency |
Compatible Equipment
- Generator Sets: C4.4
- Cold Planers: TH417D, TH360B
- Compactors: CS-54, CB-534D, CB-564D, CS-533E
- Excavators: 315C, 315D L
