Description
Cat® fastener parts are designed for specific applications based on size, strength, clamp load and past performance, information other manufacturers do not have. They are carefully selected to last until machine rebuild or end of life. Non-Cat hardware and fasteners may appear to fit your machine, but no one else knows your equipment the way we do.
These bolts are used where a separate washer is not suitable.
Features
- Cat fasteners are manufactured to precise specifications for durability, reliability and high efficiency
- Strength and Quality – Fasteners meet or exceed ISO, ASTM, ASME and SAE requirements.
- Cat bolts, nuts and washers are specifically designed to work together as a system to maximize clamping force.
- Coating meets the special requirements of different applications (RoHS compliant).
Applications
Cat bolts form a high-performance system with mating hardened washers and nuts to produce consistent, high clamping force. You can trust Cat fasteners to help you build, maintain or rebuild in most machine and shop applications worldwide.
Specifications
| Thread Direction | RH |
|---|---|
| Class or Grade | ISO 898-1 Class 8.8 |
| Thread Size | M5 mm (0 in) |
| Locking Feature | Adhesive |
| Thread Size (Diameter × Pitch) | M5X0.8 mm |
| Bolt Length | 16 mm (0.63 in) |
| Bolt Type | Flange Head Bolt |
| Material | Sealants / Adhesives Adhesive |
| Coating | Zinc Electroplated |
| Handle Length | 2 mm (0.079 in) |
| Flange Type | Smooth Flange Face |
| Flange Diameter | 11.4 mm |
Compatible Equipment
- Generator Sets: 3512B, G3516, 3512E, 3516C
- Motor Graders: 140 GC
- Track Loaders: 826H
- Engines: C32, C175-16
- Excavators: 3516E, 120 GC, 3516B, 3512C
- Wheel Loaders: 966 GC
- Off-Highway Trucks: 794 AC, 793, 798 AC, 785, 793F, 796 AC, 797F, 777D, 785D, 793D
Additional information
| Machine Model | 120 GC, 140 GC, 3512B, 3512C, 3512E, 3516B, 3516C, 3516E, 777D, 785, 785D, 793, 793D, 793F, 794 AC, 796 AC, 797F, 798 AC, 826H, 966 GC, C175-16, C32, G3516 |
|---|---|
| Equipment Type | Excavators, Wheel Loaders, Track Loaders, Motor Graders, Off-Highway Trucks, Engines, Generator Sets |
| Part Source | Genuine OEM |
