1L-5081 14 mm Thick Line Gasket
Cat® 20 mm OD shim, used to maintain precise spacing between junction boxes in the lubrication system and ensure proper alignment.
Description
Cat® fastener parts are designed for specific applications based on size, strength, clamp load and past performance, information other manufacturers do not have. They are carefully selected to last until machine rebuild or end of life. Non-Cat hardware and fasteners may appear to fit your machine, but no one else knows your equipment the way we do.
Features
Cat® fasteners are manufactured to precise specifications to be durable, reliable and efficient.
- Strength and Quality – Fasteners meet or exceed ISO, ASTM, ASME and SAE requirements.
- Cat® bolts, nuts and washers are specifically designed to work together as a system to maximize clamping force.
- Coating meets the special requirements of different applications (RoHS compliant).
- Recommended by engineers familiar with the product.
Applications
Cat® bolts form a high-performance system with matching hardened washers and nuts that produces consistently high clamping force. Cat® fasteners help you build, maintain or repair for most machine and shop applications worldwide, and they can be trusted.
Specifications
| Gasket Type | Flat |
|---|---|
| Material | Alloy Zinc |
| Outside Diameter | 20 mm (0.787 in) |
| Inside Diameter | 10.3 mm (0.406 in) |
| Coating | Zinc |
| Outer Wear Plate | 20 mm |
| Center Hole | 10.3 mm |
| Thickness | 14 mm (0.551 in) |
| Center Hole Shape | Non-Threaded |
Compatible Equipment
- Generator Sets: 3406C, 3406B, G3516, 3512B, 3516C, C7.1
- Track Loaders: 816F, 826H, 963D, 826K, 990K, 993, 826G, 824G, 992
- Cold Planers: PL83, PL87
- Motor Graders: 140G
- Compactors: 834K, 824K, 825K, C9.3B
- Engines: C15, C32, C27, C175-16, C18, C12
- Dozers: D10N, D11N, D11R, D11T, D10R, D10T2, D10T, D10, D11, D8R, D7H, D9T, D8T, D9R, D5N, D7G, D5H, D4E, D8L, D6N, D6M, D6K2, D7G2, D9L, D6R, D8N, D5K XL, D9N, D8, D6T, D7R, D5K LGP, D6G, D7, D9
- Excavators: 330 L, 637G, 6030, 3516E, 3516B, 3508B, 3512C, 637E, 385C, 6040, 330B
- Wheel Loaders: 986H, 988K, 992D, 988F, 966K, 980G, 966F, R2900G, 972G, 950, R3000H, R1300G, R1700 II, R1600H, 990H, 836, R1700G, 834
- Off-Highway Trucks: 777, 777D, 771D, 773D, 777E, 789D, 773E, 793D, 793, 785, 789
- Asphalt Pavers: AD30
Additional information
| Machine Model | 140G, 330 L, 330B, 3406B, 3406C, 3508B, 3512B, 3512C, 3516B, 3516C, 3516E, 385C, 6030, 6040, 637E, 637G, 771D, 773D, 773E, 777, 777D, 777E, 785, 789, 789D, 793, 793D, 816F, 824G, 824K, 825K, 826G, 826H, 826K, 834, 834K, 836, 950, 963D, 966F, 966K, 972G, 980G, 986H, 988F, 988K, 990H, 990K, 992, 992D, 993, AD30, C12, C15, C175-16, C18, C27, C32, C7.1, C9.3B, D10, D10N, D10R, D10T, D10T2, D11, D11N, D11R, D11T, D4E, D5H, D5K LGP, D5K XL, D5N, D6G, D6K2, D6M, D6N, D6R, D6T, D7, D7G, D7G2, D7H, D7R, D8, D8L, D8N, D8R, D8T, D9, D9L, D9N, D9R, D9T, G3516, PL83, PL87, R1300G, R1600H, R1700 II, R1700G, R2900G, R3000H |
|---|---|
| Equipment Type | Excavators, Wheel Loaders, Track Loaders, Dozers, Motor Graders, Off-Highway Trucks, Compactors, Asphalt Pavers, Cold Planers, Engines, Generator Sets |
| Part Source | Genuine OEM |
