1G-8878 Hydraulic/Transmission Oil Filter
Protect your machine with Cat® parts hydraulic transmission oil filters. The High Efficiency 1G-8878 power train filter provides contamination protection to help improve the overall performance of your Cat® machine.
Description
Smart Cat® equipment owners choose Genuine Cat filtration products to protect their machines and the businesses they depend on.
Cat High Efficiency Hydraulic and Transmission Filters enhance contamination control while maintaining excellent dirt-holding capacity. Improved filter media gives our filters higher efficiency, greater capacity and lower pressure drop. Acrylic beads maintain strict pleat spacing to prevent bunching and maximize filtration surface area throughout the life of the filter. In addition, an integrated seal ensures separation of the clean and dirty sides of the element.
While competitive products may appear to work on your machine, no one else knows your equipment like we do. Cat maintenance products are designed and built by the same company that builds your machine, so you can count on our filter elements to deliver excellent fit and performance every time. Contact MECHSC, or visit catfiltercrossreference.com and search by your competitive product part number, to switch to Cat filters today.
Features
Cat High Efficiency Hydraulic and Transmission Filters provide a higher level of protection, including the following benefits:
- Unique filter media provides superior protection
- Improves debris retention
- Improved collapse resistance
Specifications
| Length | 239.8 mm (9.441 in) |
|---|---|
| Diameter | 94.2 mm (3.709 in) |
| Flow Direction | Out-to-In |
| Filter Type | Spin-On |
| Efficiency Rating | Advanced Efficiency |
| Material | Other Mixed: Metal-Nonmetal |
| Efficiency Category | Advanced High Efficiency |
Compatible Equipment
- Generator Sets: 3512E, C4.4
- Track Loaders: 834H, 953D, 963D
- Cold Planers: TH360B, PL61
- Compactors: CB-64B, CS7, CP12 GC, CB16, CP11 GC, CW-16, CB-44B, CS12, CW-34, CS-563E, CS-56, CS-54, CB-66B, CB-564D, CS11, CS-583D, CS-533C, CB-534D, CB-434D, CS12 GC, CB13, CB15, CB10, CS-533E
- Engines: C32, C175-16
- Asphalt Pavers: AD63, AP655F, AD30, AD45, AP655F L
- Skid Steer Loaders: 216B3, 246C, 226B3, 236B3, 279C, 226B, 262C, 236
- Motor Graders: 16M, 14M, 14
- Wheel Excavators: IT14G
- Dozers: D6T, D10N, D10R, D6R III, D6R, D6R II, D5K LGP, D7G, D3G, D6N, D5G, D4G, D5N, D6T LGP, D8T, D5K XL
- Mini Excavators: 301.5
- Excavators: 325B L, 345C
- Wheel Loaders: R1700G, RM500B, 962G, 972G, 924HZ, 950G, 906K, 950H, 924GZ, 928G, 928HZ, 988H, 990H, 988G, R2900G, R1600H
- Off-Highway Trucks: 773E, 740, 798 AC, 725, 796 AC, 730, 773D, 771D, 735, 773, 794 AC
Additional information
| Machine Model | 14, 14M, 16M, 216B3, 226B, 226B3, 236, 236B3, 246C, 262C, 279C, 301.5, 325B L, 345C, 3512E, 725, 730, 735, 740, 771D, 773, 773D, 773E, 794 AC, 796 AC, 798 AC, 834H, 906K, 924GZ, 924HZ, 928G, 928HZ, 950G, 950H, 953D, 962G, 963D, 972G, 988G, 988H, 990H, AD30, AD45, AD63, AP655F, AP655F L, C175-16, C32, C4.4, CB-434D, CB-44B, CB-534D, CB-564D, CB-64B, CB-66B, CB10, CB13, CB15, CB16, CP11 GC, CP12 GC, CS-533C, CS-533E, CS-54, CS-56, CS-563E, CS-583D, CS11, CS12, CS12 GC, CS7, CW-16, CW-34, D10N, D10R, D3G, D4G, D5G, D5K LGP, D5K XL, D5N, D6N, D6R, D6R II, D6R III, D6T, D6T LGP, D7G, D8T, IT14G, PL61, R1600H, R1700G, R2900G, RM500B, TH360B |
|---|---|
| Equipment Type | Excavators, Mini Excavators, Wheel Excavators, Wheel Loaders, Track Loaders, Skid Steer Loaders, Dozers, Motor Graders, Off-Highway Trucks, Compactors, Asphalt Pavers, Cold Planers, Engines, Generator Sets |
| Part Source | Genuine OEM |
