Description
A clevis pin is a solid cylindrical pin with a flat cylindrical head on one end and a chamfer on the opposite end. Cross-hole clevis pins are secured with cotter pins, and grooved pins are secured with retaining rings.
Features
- Pin Type: Cross Hole
- Material: Steel
- Pin Diameter: 9.4 mm (0.37 in)
- Pin Length: 29 mm (1.14 in)
- Head Diameter: 12.7 mm (0.5 in)
Applications
Refer to your Operation and Maintenance Manual or contact MECHSC for more information.
Specifications
| Material | Alloy Zinc |
|---|---|
| Pin Length | 29 mm (1.142 in) |
| Pin Type | Cross Hole |
| Head Diameter | 12.7 mm (0.5 in) |
| Pin Diameter | 9.4 mm (0.37 in) |
| Material Description | Steel |
| Length | 29 mm (1.14 in) |
Compatible Equipment
- Generator Sets: 3512B, G3516, G3516C, 3406B, 3406C
- Track Loaders: 953, 826G, 963, 992, 994K, 834H, 816F, 826H, 824G
- Cold Planers: SE50 VT
- Motor Graders: 140K, 140G, 140H, 16H, 120, 12H, 120H, 16, 160K, 12K, 140 GC
- Compactors: 815, 814, 816
- Engines: C32, C15, C27, C18
- Dozers: D10N, D4E, D7G, D7H, D6M, D6R II, D9L, D9R, D6N, D7R II, D5M, D8R, D6R, D5H, D10, D11N, D8L, D5N, D9N, D6R III, D8N, D6G2 LGP, D6G2 XL, D6R XL, D7R, D6G, D7G2
- Excavators: 637E, 3516B, 3508B, 3512C, 120 GC
- Wheel Loaders: 924GZ, 950, 910, 950G, 972H, 966F, 992C, 988G, 988H, 836, 950H, 966H, 992D, 988F, 980, 972G, 834, 962G, 966K, 928G, 990H, 980G
- Off-Highway Trucks: 773, 793, 785, 789
- Skid Steer Loaders: 232D3, 226D3, 249D3, 239D3, 232D
Additional information
| Machine Model | 120, 120 GC, 120H, 12H, 12K, 140 GC, 140G, 140H, 140K, 16, 160K, 16H, 226D3, 232D, 232D3, 239D3, 249D3, 3406B, 3406C, 3508B, 3512B, 3512C, 3516B, 637E, 773, 785, 789, 793, 814, 815, 816, 816F, 824G, 826G, 826H, 834, 834H, 836, 910, 924GZ, 928G, 950, 950G, 950H, 953, 962G, 963, 966F, 966H, 966K, 972G, 972H, 980, 980G, 988F, 988G, 988H, 990H, 992, 992C, 992D, 994K, C15, C18, C27, C32, D10, D10N, D11N, D4E, D5H, D5M, D5N, D6G, D6G2 LGP, D6G2 XL, D6M, D6N, D6R, D6R II, D6R III, D6R XL, D7G, D7G2, D7H, D7R, D7R II, D8L, D8N, D8R, D9L, D9N, D9R, G3516, G3516C, SE50 VT |
|---|---|
| Equipment Type | Excavators, Wheel Loaders, Track Loaders, Skid Steer Loaders, Dozers, Motor Graders, Off-Highway Trucks, Compactors, Cold Planers, Engines, Generator Sets |
| Part Source | Genuine OEM |
