Description
Cat® J Series adapters offer unmatched manufacturing precision to protect your machine's bucket from damage. Our ground engaging tools (GET) are designed around the inherent characteristics of your Cat equipment to deliver consistent, superior protection.
Cat® two-strap adapters have a lower profile than flush-mount adapters, producing greater penetration and higher productivity.
Our adapters are durable and cast from steel that holds its hardness and offers long wear life, so your machine delivers the performance you need. Always choose Genuine Cat bucket protection to protect your investment.
Features
- J225 center adapter fits 25 mm cutting edge with 22.5 degree bevel
Applications
- Hydraulic excavator buckets
Specifications
| Width | 50 mm (1.969 in) |
|---|---|
| Overall Length | 225 mm (8.858 in) |
| Number of Holes | 0 |
| Corner Stop Angle | 0 |
| Bevel Angle | 22.5 |
| Hole Spacing | 0 mm |
| Base Edge Thickness Grade | 25 |
| Attachment Method | Weld-On |
| Bottom Bar Length | 137 mm (5.394 in) |
| Type | Two Strap |
| Size | J225 |
| Wear or Durability | Standard |
| Material | Low Alloy Steel |
| Series | J Series |
| Adapter Size | J225 |
| Wear Material | Standard Optional |
| Machine Model | Loader |
| Attachments | Weld-On |
Compatible Equipment
- Mini Excavators: 307, 308, 310, 305.5E, 307E2, 307D, 306, 305E2, 308.5, 305.5E2, 306.5, 308E2, 305.5 GC
- Excavators: 305E2 CR, 434F2, 416F2, 307E, 306E, 308E, 308D, 307.5, 306E2
