Description
Cat power train components must withstand extremely high torque, high shock loads and frequent directional shifts. Cat designs and manufactures transmission and final drive components with these demands in mind, ultimately improving power train durability and performance over the life of the machine.
Features
- Group includes carrier and sleeve bearing
- Hardened steel stator carrier
- Number of External Spline Teeth: 38
- Pitch Diameter: 96.520 mm (3.800 in)
- Sleeve Bearing Inside Diameter: 76.315 mm (3.004 in)
Applications
Service part for torque converters. Refer to your Operation and Maintenance Manual or contact MECHSC for more information.
Specifications
| Material Description | Steel |
|---|---|
| Outside Diameter | 103.12 mm (4.059 in) |
| Inside Diameter | 60 mm (2.362 in) |
| Overall Length | 269.88 mm (10.625 in) |
Compatible Equipment
- Dozers: D10R
- Off-Highway Trucks: 773E, 773D, 773F, 773
- Asphalt Pavers: AD45, AD63
Additional information
| Machine Model | |
|---|---|
| Equipment Type | |
| Part Source | Genuine OEM |
