Description
Provides filtered venting for the hydraulic tank, so air can flow into and out of the tank as needed as the fluid level in the tank changes.
Features
- Filtration Level: 7 Micron
- Vacuum relief setting: 3 kPa
- Pressure relief setting: 50 kPa
- Thread Size: 1-1/16-12
- Housing Material: Polyamide
- Filter Material: Cellulose-Based Resin-Impregnated Paper
Applications
Refer to your Operation and Maintenance Manual or contact MECHSC for more information.
Specifications
| Diameter | 46 mm (1.811 in) |
|---|---|
| Material | Polyamide Plastic |
| Material Description | Polyamide Plastic |
| Length | 64.5 mm (2.54 in) |
| Outside Diameter | 46 mm (1.81 in) |
| Standard Color | Black |
| Temperature | -30° to +100° °C (-22° to +212° °F) |
| Thread Size | 1-1/16-12 in |
Compatible Equipment
- Wheel Loaders: 966H, 950H, 928HZ, 980H, 972H, 924HZ
- Asphalt Pavers: AP-600D
Additional information
| Machine Model | |
|---|---|
| Equipment Type | |
| Part Source | Genuine OEM |
