Description
Cat motor-driven blowers circulate air for the air conditioner and heater and drive the compressor that compresses the air conditioner refrigerant. Performance suits the equipment requirements and meets your expectations.
Features
- Voltage: 27 V
- Rated Current: 7.5 A
- 2-pin connector
- Rotation: Counterclockwise from the lead end
- EMC noise suppression filter
- Environmentally sealed
Applications
For use with air conditioners and heaters on Cat machines. Refer to your Operation and Maintenance Manual or contact MECHSC for more information.
Specifications
| Material | Carbon Steel |
|---|---|
| Material Description | Steel |
| Speed | 2800 rpm |
| Outside Diameter | 78 mm (3.1 in) |
| Length | 149 mm (5.8 in) |
| Lead Length | 330, Connector Included mm (13, Connector Included in) |
Compatible Equipment
- Motor Graders: 140G
- Track Loaders: 816F
- Dozers: D10N, D11N, D6R, D6M, D6N, D5M, D9R, D6G2 XL, D8R, D7G2, D7R, D5N, D6G2 LGP, D7G, D9T
- Excavators: 637E
- Asphalt Pavers: AD45
