Description
Cat powertrain components must withstand extremely high torque, high shock loads, and frequent direction changes and shifts. Cat designs and manufactures transmission and final drive components with these demands in mind, ultimately improving powertrain durability and performance over the life of the machine. Cat friction discs work with the brake system to provide the critical friction needed to slow, stop, or hold the machine stationary.
Features
- Two-way multiple parallel grooves optimize heat dissipation.
- Hardened steel core reduces spline wear.
- (56)-tooth external spline ensures an accurate OEM fit.
- OEM friction formulation maintains braking performance to certification standards.
Applications
Refer to your Operation and Maintenance Manual or contact MECHSC for more information.
Specifications
| Material | Carbon Steel |
|---|---|
| Inside Diameter | 157.0 mm (6.181 in) |
| Outside Diameter | 239.16 mm (9.4157 in) |
| Thickness | 4.00 mm (0.157 in) |
Compatible Equipment
- Track Loaders: 973K, 963, 963D, 963K, 953K, 953D, 953
- Cold Planers: PL61
- Dozers: D6K2, D4
