Description
Cat® Shock-Resistant Halogen Lamps can withstand the vibration and harsh environmental conditions of most job sites and meet Cat water-mist-proof and vibration-resistant specifications. Shock-resistant halogen lamps offer longer bulb life and greater brightness than standard bulbs. When you need an economical product for long working hours and high-vibration applications, you can count on the Cat Shock-Resistant Halogen Work Light.
Features
- Low beam lens pattern
- Vertical mount
- 24V
- Integral DT connector
- No mounting bracket required
Applications
- High-vibration applications
Specifications
| Mounting Type | Vertical |
|---|---|
| Length | 137 mm (5.39 in) |
| Beam Pattern | Low Beam |
| Connector Type | Integral DT |
| Lighting Type | Halogen Work Light |
| Height | 152 mm (5.98 in) |
| Lens Type | Low Beam |
| Width | 147 mm (5.79 in) |
| Voltage | 24 Volts |
Compatible Equipment
- Motor Graders: 18, 16, 16M3, 12H, 140H, 16M, 16H, 120H
- Dozers: D10R
- Excavators: 637G, 621G
- Wheel Loaders: 992K
- Off-Highway Trucks: 773, 785D, 773E, 773F, 797F, 789D, 793F, 794 AC, 793D
- Skid Steer Loaders: 24
