Description
Cat plug lock wiring connections lock the wiring connection based on pin count and locking mechanism.
Features
- Nylon
- Integrated latch
- Resistant to engine oil and fuel
Applications
Cat plug groups are used as reliable wire-to-wire or wire-to-device connections. Refer to your Operation and Maintenance Manual or contact MECHSC for more information.
Specifications
| Overall Height | 17.8 mm (0.7 in) |
|---|---|
| Connector Type | Pin |
| Overall Width | 17.8 mm (0.7 in) |
| Overall Length | 48.3 mm (1.9 in) |
| Pin | 2 |
Compatible Equipment
- Generator Sets: 3516C, C9
- Track Loaders: 990K, 826K, 973K, 826H
- Cold Planers: PL61, PL83, PL72, PM622, PM620, PL87
- Compactors: 825K, 824K, C9.3B, 834K, C-9
- Engines: C7, C13, C15, C27, C32, C11, C18, C175-16
- Excavators: 336D2, 336D, 374F, 390F L, 329D, 349F L, 330D L, 6060, 336E LH, 336D L, 336F LN, 329D L, 325D L, 336F L XE, 324D, 3516B, 3508B, 374F L, 390F, 352F, 349E L, 621K, 349E, 349E L VG, 621H, 340D2 L, 340D L, 6030, 621G, 336F, 325D, 336D2 L, 330C L, 336F L, 324D L, 330D, 336D2 XE, 326D L, 336E, 328D LCR, 336E L, 330C, 336D2 GC, 637K, 637G, 637E, 6040, 336E LN, M325D L MH, 336E H, 385C
- Asphalt Pavers: AD45
- Skid Steer Loaders: 3126B
- Motor Graders: 18, 160K, 16M3, 16, 140K, 14, 12K
- Wheel Excavators: MD6200
- Dozers: D9R, D4, D7, D9, D11, D10, D8, D6R LGP, D8T, D6R III, D6R II, D6R, D6T LGP, D6T, D7E, D7R, D6K2, D8R, D6R XL, D9T, D6N
- Wheel Loaders: RM500B, R1700G, 966L, 950H, 988K, 966K, 972L, 986H, R1600H, 980L
- Off-Highway Trucks: 740 GC, 772G, 745, 770G, 735, 740, 745C, 740B, 725, 730, 725C2
