Description
V-rings are designed specifically to exclude external contamination. They are typically designed as an integral part of a sealing system together with other seals, but can also be used alone to protect a cavity.
Features
Cat® V-ring seals are versatile and fit a wide range of shaft diameters.
Cat® sealing systems protect more expensive parts from leakage and contamination. Genuine Cat® seals protect your investment.
Applications
V-rings are used in a variety of rotating applications, including axles, motors and the operator environment.
Specifications
| Outside Diameter | 100.00 mm (3.937 in) |
|---|---|
| Overall Width | 11.00 mm (0.433 in) |
| Primary Seal Material | NBR (Nitrile Rubber) |
| Seal Type | V-Ring |
| Shaft Diameter | 90.00 mm (3.543 in) |
Compatible Equipment
- Off-Highway Trucks: 725C2, 725, 730, 735
Additional information
| Machine Model | |
|---|---|
| Equipment Type | |
| Part Source | Genuine OEM |
