Description
Cat® fastener parts are designed for specific applications based on size, strength, clamp load and past performance, information other manufacturers do not have. They are carefully selected to last until machine rebuild or end of life. Non-Cat hardware and fasteners may appear to fit your machine, but no one else knows your equipment the way we do.
Features
* Cat fasteners are manufactured to precise specifications for durability, reliability and efficiency.
* Strength and quality – fasteners meet or exceed ISO, ASTM, ASME and SAE requirements.
* Cat bolts, nuts and washers are specifically designed to work together as a system to maximize clamping force.
* Coatings meet the special requirements of different applications (RoHS compliant).
* This type of washer maintains constant pressure or tightness under heavy loads.
Applications
Cat bolts form a high-performance system with mating hardened washers and nuts to produce consistent, high clamping force. You can trust Cat fasteners to help you build, maintain or rebuild in most machine and shop applications worldwide.
Specifications
| Coating | None |
|---|---|
| Material | Stainless Steel |
| Gasket Type | Helical Spring-Split |
| Outside Diameter | 22.07 mm (0.869 in) |
| Inside Diameter | 12.75 mm (0.502 in) |
| Thickness | 3.18 mm (0.125 in) |
Compatible Equipment
- Generator Sets: 3512B, 3516C, G3516C, G3516, 3512E
- Track Loaders: 992, 995
- Compactors: CS12, CP12 GC, CS11, CP11 GC, CS12 GC, C-15
- Engines: C32, C15, C18, C175-16
- Excavators: 301.7D, 316 GC, 336D L, 320D FM, 320C, 313D2, 637K, 657G, 637G, 3516B, 416F2, 3508B, 621H, 3512C, 320D3 GC, 3516E, 6030, 6060, 621K, 6020B, 6040
- Asphalt Pavers: AD63
- Wheel Excavators: M322D, M315D2, MD6250, M320D2, MD6310, M313D, M315D, M317D2, M320, MD6200
- Dozers: D11, D10
- Mini Excavators: 305E2, 301.7D CR, 307E2, 305.5E2
- Wheel Loaders: 924K, 938K, 938M, 926M, 928HZ
- Off-Highway Trucks: 794 AC, 793F, 789D, 785, 793, 789, 798 AC, 796 AC, 797F
Additional information
| Machine Model | 301.7D, 301.7D CR, 305.5E2, 305E2, 307E2, 313D2, 316 GC, 320C, 320D FM, 320D3 GC, 336D L, 3508B, 3512B, 3512C, 3512E, 3516B, 3516C, 3516E, 416F2, 6020B, 6030, 6040, 6060, 621H, 621K, 637G, 637K, 657G, 785, 789, 789D, 793, 793F, 794 AC, 796 AC, 797F, 798 AC, 924K, 926M, 928HZ, 938K, 938M, 992, 995, AD63, C-15, C15, C175-16, C18, C32, CP11 GC, CP12 GC, CS11, CS12, CS12 GC, D10, D11, G3516, G3516C, M313D, M315D, M315D2, M317D2, M320, M320D2, M322D, MD6200, MD6250, MD6310 |
|---|---|
| Equipment Type | Excavators, Mini Excavators, Wheel Excavators, Wheel Loaders, Track Loaders, Dozers, Off-Highway Trucks, Compactors, Asphalt Pavers, Engines, Generator Sets |
| Part Source | Genuine OEM |
