149-5069 Female Blade Terminal

Description

Cat Female Blade Terminals are used in electrical connectors. Cat Male Blade Terminals are inserted into the Cat Female Terminals on the mating connector to make the electrical connection.

Features

• Crimp-style connector receptacle
• Integrated latch
• Mating Tab Size: 6.35 X 0.81 mm (0.25 X 0.032 in)
• Tin-Plated Brass
• Wire Size (AWG): 20-14
• Easy to connect and disconnect

Applications

Cat blade terminals provide a reliable mating connection between wires or between a wire and equipment. Refer to your Operation and Maintenance Manual or contact MECHSC for more information.

Specifications

Compatible Equipment

• Generator Sets: 3512B, C7.1
• Motor Graders: 349 GC, 316F
• Wheel Excavators: M315D2, M320, M317D2, M315D, M313D, M320D2, M322D, M315, M315GC
• Mini Excavators: 307C, 307D
• Excavators: 313, 313 GC, 374, 330D L, 316 GC, 352, 315 GC, 320 GC, 326, 340, 323, 355, 325, 330 GC, 320, 333, 312 GC, 336, 320D FM, 320D L, 323GC, 335, 350, 323 GX, 395, 330D2, 324D L, 312D L, 312D, 320D2 GC, 329D L, 325C, 330GC, 312D2 L, 320D GC, 320C, 328D LCR, 313D, 330D2 L, 318D2 L, 323D2 L, 336D L, 313D2, 320D2 L, 336F LN, 324D, 325D L, 312D2, 320D RR, 336 GC, 320D3, 336D2 L, 336F, 323D2, 323D L, 313F L, 320B, 336F L, 329E L, 311B, 313F LGC, 312C, 315D L, 311D LRR, 336E LH, 325D, 313D2-GC, 312D2 GC, 336D2 XE, 325B, 325B L, 326D L, 315C, 314D LCR, 313D2 GC, 312F, 315, 318D2, 336F L XE, 318D L, 336D2 GC, 315F LCR, 325C L, 314D CR, 336E LN, 312C L, 320E, 349E L VG, 345D, 345D L, 390D, 349D L, 374F L, 345C, 345C L, 349, 390F, 352F, 340D2 L, 349E L, 365C L, 345 GC, 320 GX, 313 GX, 323 GC, 330D, 350MHPU, 336E L, 323D, 330B, M325D L MH, 312 GX, 316 GX, 326 GC, 3101, 320D3 GC, 330C L, 326GC, 336E, 329E, 340D L, 385C L, 345B, 365C, 349E, 320D, 330, 320D2, 329D, 326D2 L, 336D, 336D2, 329D2, 329D2 L, 326D2, 308D, 349D2 L, 390F L, 349D2, 390D L, 374D L, 349D, 374F
• Wheel Loaders: 966 GC
• Off-Highway Trucks: 794 AC, 798 AC, 796 AC
• Skid Steer Loaders: 313D2 LGP
