Description
Also known as a threaded rod. Usually fully threaded or threaded at both ends.
Cat® fasteners and hardware are designed for specific applications based on size, strength, clamp load and past performance, information other manufacturers do not have. They are carefully selected to last until machine rebuild or end of life. Non-Cat hardware and fasteners may appear to fit your machine, but no one else knows your equipment the way we do.
Features
- Cat fasteners and hardware are manufactured to precise specifications for durability, reliability and high efficiency
- Strength and Quality – Fasteners meet or exceed ISO, ASTM, ASME and SAE requirements
- Coating meets the special requirements of different applications (RoHS compliant)
Applications
- Cat fasteners and hardware are trusted to build, maintain or repair most machines and shop applications worldwide
Specifications
| Material Description | ISO 898-1 Class 10.9 |
|---|---|
| Stud Thread Pitch | 1.5 |
| Grade | 10.9 |
| Locking Feature | Interference Thread and Patch |
| Stud Thread Size | M10 |
| Remarks | Thread Length (mm) 20, Stud End Thread Length: 15 |
| Coating | None |
| Hole Thread Pitch | 1.5 |
| Thread Size | M10 mm |
| Height | 25.4 mm (1 in) |
| Length | 40 mm (3.75 in) |
| Width | 69.85 mm |
| Material | Coating Fluid |
Compatible Equipment
- Generator Sets: C7.1, C4.4
- Track Loaders: 953K, 953D, 953
- Compactors: CB-66B, CW-34, CS-54, CS-56, CS-563E, CB-44B, CB16, CS11, CB-64B, CB10, CB15, CB13, CS-54B, CS-533E
- Engines: C6.6
- Excavators: 330, 312E L, 326, 312E, 320, 320 GC, 330GC, 323, 335F LCR, 320E, 315F LCR, 312F, 330 GC, 313F L, 416F2, 434F2, 428F, 320 GX
- Asphalt Pavers: AP-600D
- Motor Graders: 120, 140 GC, 316F
- Wheel Excavators: M315D, IT14G, M322D, M313D, M315, M315GC
- Dozers: D3K2 LGP, D5K2 XL, D6N, D5K LGP, D5K XL
- Wheel Loaders: 926M, 938M, 928G, 938K, 924GZ, 924K, M314
Additional information
| Machine Model | 120, 140 GC, 312E, 312E L, 312F, 313F L, 315F LCR, 316F, 320, 320 GC, 320 GX, 320E, 323, 326, 330, 330 GC, 330GC, 335F LCR, 416F2, 428F, 434F2, 924GZ, 924K, 926M, 928G, 938K, 938M, 953, 953D, 953K, AP-600D, C4.4, C6.6, C7.1, CB-44B, CB-64B, CB-66B, CB10, CB13, CB15, CB16, CS-533E, CS-54, CS-54B, CS-56, CS-563E, CS11, CW-34, D3K2 LGP, D5K LGP, D5K XL, D5K2 XL, D6N, IT14G, M313D, M314, M315, M315D, M315GC, M322D |
|---|---|
| Equipment Type | Excavators, Wheel Excavators, Wheel Loaders, Track Loaders, Dozers, Motor Graders, Compactors, Asphalt Pavers, Engines, Generator Sets |
| Part Source | Genuine OEM |
