Description
Cat plug group connectors provide a pin-and-socket connection system for highly durable, sealed electrical connections in Cat heavy equipment.
Features
- Blue polyphthalamide (PPA) 2-pin connector plug
- Integrated latch
- Durable
Applications
Cat connector plug groups use reliable wires between wires or between a wire and equipment. Refer to your Operation and Maintenance Manual or contact MECHSC for more information.
Specifications
| Material | Polyphthalamide (PPA) Plastic |
|---|---|
| Overall Depth | 11 mm (0.4 in) |
| Pin | 2 |
| Material Description | Polyphthalamide (PPA) |
| Wire Gauge | 16-18 AWG |
| Overall Length | 22.1 mm (0.9 in) |
| Connector Type | 2 Pin |
| Standard Color | Blue |
| Overall Width | 19 mm (0.7 in) |
Compatible Equipment
- Motor Graders: 120H
- Engines: C7
- Dozers: D6N, D5N
- Excavators: 312D L, 325C, 325C L, 314D LCR, 311D LRR, 312D, 313D, 315D L, 314D CR, 3126
- Skid Steer Loaders: 3126B
