Description
Cat® flat serrated cutting edges feature unmatched manufacturing precision to protect your machine's blade from damage. Our GET is designed around the inherent characteristics of your Cat equipment to provide consistently excellent protection.
Cat serrated cutting edges apply greater down pressure and are better suited to road surface work. Cat cutting edges and end bits are designed as a balanced system, providing high strength for excellent breakage resistance and maximum protection against bottom and face wear of the cutting edge, so you work longer, move more material and reduce downtime.
Our cutting edges are durable and cast from steel that holds its hardness and offers long wear life, so your machine delivers the performance you need. Always choose Genuine Cat bucket protection to protect your investment.
Features
- High impact and abrasion resistance
- High penetration rate
Application
- 12' Blade
- ¾" Bolt Holes
- Packed gravel, frozen ground and ice
Specifications
| Serrated | Serrated |
|---|---|
| Machine Model | Grader |
| Width | 405.892 mm (15.984 in) |
| Thickness | 74.93 mm (2.95 in) |
| Wear or Durability | Standard |
| Overall Length | 1216.8 mm (47.906 in) |
| Cutting Edge Shape | Flat |
| Hole Spacing | 152.4 mm (6 in) |
| Serration Gap | 40.6 mm (1.598 in) |
| End Hole Spacing | 76.2 mm (3 in) |
| Cutting Edge Type | Serrated |
| Hole Size | 1-in Plow Bolt (28 mm square) |
| Serration | 61 mm (2.402 in) |
| Number of Holes | 9 |
Compatible Equipment
- Skid Steer Loaders: 24
Additional information
| Machine Model | |
|---|---|
| Equipment Type | |
| Part Source | Genuine OEM |
