Description
The lip seal is for rotating applications, preventing oil inside the machine from leaking out and protecting the machine from external contamination. The seal is professionally designed for long-lasting, reliable performance and provides extra protection in most extreme environments.
Features
- Seal Material: FKM
- Type: DBI
- Bore Diameter: 95.28 mm (3.75 in)
- Shaft Diameter: 69.85 mm (2.75 in)
- Outside Diameter: 95.4 mm (3.76 in)
- Seal Width: 12.7 mm (0.5 in)
Applications
Refer to your Operation and Maintenance Manual or contact MECHSC for more information.
Specifications
| Material | Plastic Plastic |
|---|---|
| Material Description | FKM |
| Hole Diameter | 95.28 mm (3.751 in) |
| Shaft Diameter | 69.85 mm (2.750 in) |
| Outside Diameter | 95.4 mm (3.755 in) |
| Width | 12.7 mm (0.500 in) |
Compatible Equipment
- Wheel Loaders: 924GZ, 928G, 928HZ
- Off-Highway Trucks: 785D, 789D
Additional information
| Machine Model | |
|---|---|
| Equipment Type | |
| Part Source | Genuine OEM |
