Description
A nut is a fastener used to secure components to a threaded shaft or rod. It is typically made of a strong material such as steel, is round, and has small notches around the circumference of the nut that are specially designed to fit into corresponding holes in the component.
Attributes
Manufactured to precise technical specifications, rugged, durable, and reliable, delivering outstanding production
Designed to handle high torque and vibration stress.
Applications
The nut is used to connect components in hydraulic cylinders and is mainly used on Cat® 206, 206B, 212, 212B, M312, M313C, M313D, M314, M314F, M315, M315C, M315D, M315F, M316, M316F, M317, M317D, M318, M318C, M318D, M320, M322C, M322D, M324D, M325C, MH3022, MH3024, and MH3026 excavators, and M318D, M322D, MH3022, MH3024, and MH3026 material handlers.
Specifications
| Thread Direction | LH |
|---|---|
| Drive Chain | 99999.99 mm (3937.008 in) |
| Thread Size | M35 mm (0 in) |
| Class or Grade | See Drawing |
| Thread Size (Diameter × Pitch) | M35x1.5 mm |
| Thickness | 11 mm (0.43 in) |
| Outside Diameter | 50 mm (1.96 in) |
| Nut Model | Round (Wrench or Bearing) |
| Thread | M35 x 1.5 |
| Weight | 0.06 kg (0.13 lb) |
Compatible Equipment
- Wheel Excavators: M315, M315D2, M315D, M317D2, M313D, M320
- Wheel Loaders: M314
Additional information
| Machine Model | |
|---|---|
| Equipment Type | |
| Part Source | Genuine OEM |
