114-2583 M8x1.25 Thread Interference Stud

Description

Also known as a threaded rod. Usually fully threaded or threaded at both ends.

Cat® fasteners and hardware are designed for specific applications based on size, strength, clamp load and past performance, information other manufacturers do not have. They are carefully selected to last until machine rebuild or end of life. Non-Cat hardware and fasteners may appear to fit your machine, but no one else knows your equipment the way we do.

Features

Cat fasteners and hardware are manufactured to precise specifications for durability, reliability and high efficiency
Strength and Quality – Fasteners meet or exceed ISO, ASTM, ASME and SAE requirements
Coating meets the special requirements of different applications (RoHS compliant)

Applications

Cat fasteners and hardware are trusted to build, maintain or repair most machines and shop applications worldwide

Specifications

Material	Low Alloy Steel
Coating	None
Material Description	ISO 898-1 Class 10.9
Locking Feature	Interference Thread and Patch
Stud Thread Pitch	1.25
Length	37 mm
Hole Thread Pitch	1.25
Thread Size	M8 mm
Stud Thread Size	M8
Grade	10.9
Remarks	Thread Length (mm) 21, Stud End Thread Length: 12

Compatible Equipment

Generator Sets: C4.4, C7.1
Cold Planers: PL61
Wheel Excavators: M320, M315, IT14G
Compactors: CP12 GC, CS74B, CS68B, CS78B, CS12 GC, CS56B, CP11 GC, CS7, CS12, CP56B, CB10
Dozers: D4, D6K2, D1
Mini Excavators: 308, 310
Excavators: 313 GC, 316 GC, 313, 120 GC, 323 GX, 323 GC, 326 GC, 320, 312 GX, 312 GC, 313 GX, 316 GX, 325, 315 GC, 315, 320 GC, 323, 432
Wheel Loaders: M314, 910
Asphalt Pavers: AP655F
Skid Steer Loaders: 236

Machine Model	120 GC, 236, 308, 310, 312 GC, 312 GX, 313, 313 GC, 313 GX, 315, 315 GC, 316 GC, 316 GX, 320, 320 GC, 323, 323 GC, 323 GX, 325, 326 GC, 432, 910, AP655F, C4.4, C7.1, CB10, CP11 GC, CP12 GC, CP56B, CS12, CS12 GC, CS56B, CS68B, CS7, CS74B, CS78B, D1, D4, D6K2, IT14G, M314, M315, M320, PL61
Equipment Type	Excavators, Mini Excavators, Wheel Excavators, Wheel Loaders, Skid Steer Loaders, Dozers, Compactors, Asphalt Pavers, Cold Planers, Generator Sets
Part Source	Genuine OEM

Machine Model

120 GC, 236, 308, 310, 312 GC, 312 GX, 313, 313 GC, 313 GX, 315, 315 GC, 316 GC, 316 GX, 320, 320 GC, 323, 323 GC, 323 GX, 325, 326 GC, 432, 910, AP655F, C4.4, C7.1, CB10, CP11 GC, CP12 GC, CP56B, CS12, CS12 GC, CS56B, CS68B, CS7, CS74B, CS78B, D1, D4, D6K2, IT14G, M314, M315, M320, PL61

Equipment Type

Excavators, Mini Excavators, Wheel Excavators, Wheel Loaders, Skid Steer Loaders, Dozers, Compactors, Asphalt Pavers, Cold Planers, Generator Sets

Part Source

Genuine OEM
