Description
This J700 heavy duty retainer group is a two-coil retainer with far greater grip on the pin than standard pins and retainers. This coil spring seat absorbs side loads and eliminates retainer stretch problems. The careful system design reduces the pin movement that occurs when a tip has been in use too long and the pin and retainer have worn, or when side loads on the tip cause the retainer to stretch.
Applications
- Use with specific heavy duty pin
- Suitable for installing J700 tips and adapters
Specifications
| Thickness | 11.5 mm (0.453 in) |
|---|---|
| Outside Diameter | 70 mm (2.756 in) |
| Size | J Series |
| Length | 72.39 mm (2.85 in) |
| Height | 11.43 mm (0.45 in) |
| Width | 72.39 mm |
Compatible Equipment
- Track Loaders: 993
- Excavators: 374, 395, 3101, 390D, 385C L, 385C, 385C FS, 385B, 374F L, 365B, 345C L, 365B L, 390D L, 374D L, 390F L
- Wheel Loaders: 992C
